1. Electric tilting cab, convenient maintenance;
2. Large arc cab front windshield, wide field of vision. Standard with air conditioner, driving comfort is greatly improved;
3. Multi-functional control dest, and seats can be adjusted in four directions;
4. The chasis and lifting system structural parts are analyzed by CAE, which are safe and reliable;
5. Add the oil level meter of the fuel and hydraulic oil box, reasonable arrangement of the air filter and fuel filter position, easy maintenance.
Model Designation | CPCD120 | CPCD135 | CPCD140 | CPCD150 | CPCD160 | |
Model designation | kg | 12000 | 13500 | 14000 | 15000 | 16000 |
Load capacity | mm | 900 | 600 | 900/1200 | 600/900/1200 | 600/900/1200 |
Load center | mm | 8000 | 8000 | 8000 | 8000 | 8000 |
Min.outside turning radius | mm | 4450 | 4450 | 4750/5100 | 4500/4750/5100 | 4500/4750/5100 |
