1. Appearance innovation design: continuing the characteristics of serialization and familialization.
2. The lifting speed, forward and backward movement speed and climbing ability are upgraded which provides more outstanding work efficiency.
3. EPS electronic power steering, providing the forklift with lightweight and flexible. Efficient and quiet operation.
4. Equipped with five sets of independent braking system and descending OPS, more secure; Mast lifting more than 5m to limit the hydraulic operating speed, improve the stability of the mast high level operation.
5. Optional built-in charger, rubber tires (drive wheels) and endurance plate roof, lights and other configurations.
6. Efficient and convenient maintenance: the snap-on split hood is easy to disassemble and the detachable side door increases the maintenance space.
Model Designation | CQD15 | CQD18 | CQD20 | CQD25 | |
Load Capacity | kg | 1500 | 1800 | 2000 | 2500 |
Load Center | mm | 500 | 500 | 500 | 500 |
Max. lifting height | mm | 6750 | 6750 | 7400 | 7400 |
Min. outside turning radius | mm | 1615/1590 | 1775/1730 | 1795 | 1965 |
Battery Voltage | V | 48/80 | 48/80 | 48/80 | 48/80 |
Controller | ZAPI | ||||
Battery | Lithium battery | ||||
Other | Optional: Lead-acid battery | Optional: Lead-acid battery | Optional: Lead-acid battery | Optional: Lead-acid battery |
