Commonly used in the warehouse and production line and production line between the different processes of the material transfer.
1. Side placed automatic charging and integrated charger;
2. Equipped with maintenance free AC steering motor;
3. No load reduction at 3m with a load of 1.6 ton;
4. AGV has compact structure,occupying minimal passage space.
Model Designation | CDD16-AGV1C1LI | CDD15-AGV4A5LI | |
Typology | / | Stacker | Stacker |
Navigation | / | Laser navigation | Laser navigation |
Load Capacity | kg | 1600 | 1500 |
Max. lifting height | mm | 3600 | 2000 |
Max. travelling speed | km/h | 4 | 5 |
Min. turning radius | mm | 1340 | 1190 |
Communication mode | / | 5G/WIFI | 5G/WIFI |
Battery voltage | V/Ah | 24/173 | 24/100 |
Weight | kg | 1090 | 800 |
